- Place of Origin: chengdu
- Brand Name: ruiweisheng
- Model Number: HD-C50
Characteristic
1 the high frequency vibration of high frequency (160HZ/S), vibration force (8.7KN), small amplitude (0.38mm), a large range of radiation frequency 160HZ current: 3.94A
(1.5m), the fluidity and the plasticity of concrete are increased, the density of components is improved, and the shape is fast, and the quality can be greatly improved. 9900 RPM can be achieved at a high speed.
2 reduce template loss. As the vibration frequency is high, the amplitude is small, the energy consumption of the steel template deformation is small, and the service life of the template is prolonged.
3 easy to use. Due to the small size, light weight (only 23 kg / Taiwan), and the use of fast charge card structure, fixed in the template only need to tighten a screw can be used. Handling a just 30 seconds, than the use of ordinary external vibrator save installation auxiliary time 75%, save manpower 75%.
4 service life is four times more than ordinary. Because ZKF type vibrator high efficiency, vibration time is only 30 ~ 40 seconds to stop, thus greatly improve the service life of the vibrator, reduce maintenance costs, reduce the construction cost.
5 due to strong excitation force, for the construction of a high bridge column can also be a molding.
The 6 is the first domestic high frequency fast loading type vibrator, after nearly ten years of continuous technological improvement, technology is very mature.
7 the product quality is reliable, the service life is long, and uses the quick charge structure, can accelerate the speed of the beam.
8 to make the construction quality has been very significantly improved, and get a lot of project department, the supervision department of the recognition and praise.
Two. Technical parameters
Model
Exciting force
KN
Vibration frequency
HZ
amplitude
Mm
Input voltage V
Vibration frequency r/min
power
KW
weight
KG
ZF200
Eight point seven
One hundred and sixty
Zero point three eight
Three hundred and eighty
6000-9000
One point five
Twenty-three
Scope of application
With the high frequency power supply unit supporting the use of prefabricated, mainly used in large-scale concrete structures such as highway, railway, bridge, culvert concrete girders, especially T beam and I-beam etc..
Four. Compared with ordinary high frequency vibrator vibrator
The traditional attached type vibrator
High-frequency quick assembling attached type vibrator
frequency
50HZ
frequency
160HZ
amplitude
2.5mm
amplitude
0.38mm
Vibration time
>120 seconds
Vibration time
30-40 seconds
Exciting force
10KN
Exciting force
8.7KN
power
1.5KW
power
1.5KW
Loading and unloading a time required
>4 minutes
Loading and unloading a time required
About 30 seconds.
weight
37Kg
weight
23Kg
